285-197 2 Conductor Ground Terminal Block with Power Cage Clamp are designed for Conductors of 95mm2. It have Lateral Marker Slot and Suitable for DIN 35 x 15 Rail.Green and Yellow Color Surface
Suitable for Every Application
1 Meets the most stringent requirements, including those specified for railway and marine applications
2 Heat- and cold-resistant –even under the heaviest of loads
Always Reliable
1 Optimum clamping force –independent of operator skill
2 100% reliable with vibration-proof, thermal cycling resistant, gas-tight connections
Fast Termination
Eliminate time-consuming preparation – no ring terminals or ferrules required
No expensive torque wrenches or calibration required
Up to 60% faster than wiring with screw terminal blocks
Add to favorites
Your favorite posts saved to your browsers cookies. If you clear cookies also favorite posts will be deleted.
Material Data
Color Green Yellow
Insulating Material PA66
Clamping Spring Material Chrome Nickel Spring Steel
Contact Material Copper
Rating per IEC/EN 60664-1
Rated Voltage (III/3) 1000V
Rated Impulse Voltage (III/3) 12kV
Rated Current 232A
Connection Data
Connection Technoloty POWER CAGE CLAMP
Solid Conductor 25-95mm2 / 4-4/0AWG
Stranded Conductor 25-95mm2 / 4-4/0 AWG
Fine Stranded Conductor 25-95mm2 / 4-4/0AWG
Strip Length 35mm
No of Poles 2
Type of Wiring Side Entry Wiring
Geometrical Data
Width 25mm
Height from Upper Edge of Din-35 Rail 101mm
Depth 107mm
For more details specification , Please visit : 285-197
