HCT-IT-0525I Crimping Pliers For Insulated Terminals 0.5-2.5mm2

HCT-IT-0525I Crimping Pliers For Insulated Terminals 0.5-2.5mm2

Product Name : Crimping Pliers with Short Design

Item No : HCT-IT-0525I

Color of Handle : Orange , Black , Red & Blue

Application : Insulated Terminals

Crimping Range : 0.5-2.5mm2

AWG : 22-14

Weight : 0.37 KGS

Length : 190mm

tag:

FavoriteLoadingAdd to favorites
  • Favorite list is empty.
FavoriteLoadingClear favorites

Your favorite posts saved to your browsers cookies. If you clear cookies also favorite posts will be deleted.

Item No Application Crimping Range Weight ( KGS ) Length (mm)
mm2 AWG
HCT-IT-02525I Insulated Terminals 0.25-2.5 24-14 0.37 190
HCT-IT-0525I Insulated Terminals 0.5-2.5 22-14 0.37 190
HCT-NIT-07525I Non-Insulated Terminals 0.75-2.5 20-14 0.37 190
HCT-NIT-02525I Non-Insulated Terminals 0.25-2.5 24-14 0.37 190
HCT-NIT-0560I Non-Insulated Terminals 0.5-6.0  22-10 0.37 190
HCT-WF-0560I Wire Ferrules 0.5-6.0 22-10 0.37 190
HCT-WF-02560I1 Wire Ferrules 0.25-6.0 24-10 0.37 190
HCT-WF-02560I2 Wire Ferrules 0.25-6.0 24-10 0.37 190
HCT-WF-616I Wire Ferrules 6-16 10-6 0.37 190
HCT-OBT-0525I Non-Insulated Tab and Receptacles 0.5-2.5 22-14 0.37 190
HCT-OBT-02510I Tab 2.8 0.25-1.0 24-18 0.37 190
HCT-OBT-0515I Tab 2.8 , 4.8 , 6.3 0.5-1.5 22-14 0.37 190
HCT-OBT-00805I  D-Sub 2.0mm, 2.5mm, 2.54mm 0.08-0.5 28-22 0.37 190
HCT-OBT-00808I1 D-Sub 2.0mm, 2.54mm 0.08-0.5 28-22 0.37 190
HCT-OBT-008014I D-Sub 1.25mm, 1.54mm 0.08-0.14 28-26 0.37 190
HCT-OBT-0325I SM C3 PH2.0 VH2.54 3.96 0.3-2.5 24-14 0.37 190
